Panasonic MINAS A5 MHMJ042G1C Servo Motor 200V 400W
$0.00
Tax included
Product DescriptionPanasonic MINAS A5 MHMJ042G1C Servo Motor 200V 400WThe Panasonic MINAS A5 MHMJ042G1C Servo Motor represents the pinnacle of precision and reliability in motion control technology. Designed for high-performance applications, this advanced servo motor operates at 200V and delivers a robust output of 400W. It combines state-of-the-art engineering with Panasonic's renowned quality to provide unparalleled accuracy and efficiency in industrial automation systems.Key Features:High Precision and Performance: The MINAS A5 series is engineered for exceptional precision, offering minimal backlash and superior torque control. The MHMJ042G1C model ensures accurate positioning and smooth motion, essential for complex machinery and robotics.Advanced Feedback Control: Equipped with high
Security policy
(edit with the Customer Reassurance module)
Delivery policy
(edit with the Customer Reassurance module)
Return policy
(edit with the Customer Reassurance module)
Product Description
Panasonic MINAS A5 MHMJ042G1C Servo Motor 200V 400W
The Panasonic MINAS A5 MHMJ042G1C Servo Motor represents the pinnacle of precision and reliability in motion control technology. Designed for high-performance applications, this advanced servo motor operates at 200V and delivers a robust output of 400W. It combines state-of-the-art engineering with Panasonic's renowned quality to provide unparalleled accuracy and efficiency in industrial automation systems.
Key Features:
- High Precision and Performance: The MINAS A5 series is engineered for exceptional precision, offering minimal backlash and superior torque control. The MHMJ042G1C model ensures accurate positioning and smooth motion, essential for complex machinery and robotics.
- Advanced Feedback Control: Equipped with high-resolution encoders, the servo motor delivers real-time feedback for precise control. This feature enhances performance in dynamic environments, ensuring optimal response and stability.
- Durable Construction: The servo motor's robust design includes high-quality bearings and materials that withstand demanding operational conditions. It is built to last, reducing maintenance needs and extending service life.
- Compact and Efficient Design: The MINAS A5 MHMJ042G1C is designed to be compact, making it ideal for applications with space constraints. Its efficiency ensures reduced energy consumption and operational costs.
- Versatile Applications: Suitable for a wide range of industrial applications, including automation, robotics, CNC machinery, and packaging systems. The servo motor is adaptable to various operating environments and requirements.
Technical Specifications:
- Voltage: 200V
- Power Output: 400W
- Motor Type: AC Servo Motor
- Feedback: High-resolution encoder
- Control: Advanced digital signal processing
- Dimensions: [Provide specific dimensions]
- Weight: [Provide weight]
- Mounting Type: [Specify mounting type]
Applications:
The Panasonic MINAS A5 MHMJ042G1C Servo Motor is ideal for use in high-precision tasks such as:
- Robotics: Enhanced control for precise movement and positioning.
- CNC Machines: Superior accuracy for cutting, milling, and drilling applications.
- Automation Systems: Reliable performance for conveyor systems and material handling.
- Packaging Machinery: Efficient and accurate motion for packaging and labeling processes.
Warranty and Support:
Panasonic offers comprehensive support and a warranty on the MINAS A5 MHMJ042G1C Servo Motor, ensuring peace of mind and reliable performance for your critical applications.
Panasonic MINAS A5 Family MHMJ042G1C Servo Motor 200V 400W
Spec Detail
| Item | Specifications |
|---|---|
| Part Number | MHMJ042G1C |
| Details | High inertia, Connector type, IP65 |
| Family Name | MINAS A5 |
| Series | MHMJ Series |
| Type | High inertia |
| Special Order Product | Special Order Product |
| Cautions for Special ordering product | Please avoid the motor, or equipment containing the motor to be distributed to Japan, or other regions through Japan. |
| Enclosure | IP65 |
| About Enclosure | Except rotating portion of output shaft and leadwire end. |
| Environmental Conditions | For more details, please refer to the instruction manual. |
| Flange sq. dimension | 60 mm sq. |
| Flange sq. dimension (Unit:mm) | 60 |
| Motor lead-out configuration | Connector |
| Motor encoder connector | Connector |
| Power supply capacity (kVA) | 0.9 |
| Voltage specifications | 200 V |
| Rated output | 400 W |
| Rated current (A (rms)) | 2.6 |
| Holding brake | without |
| Mass (kg) | 1.4 |
| Oil seal | with |
| Shaft | Round |
| Rated torque (N ⋅ m) | 1.3 |
| Momentary Max. peak torque (N ⋅ m) | 3.8 |
| Max. current (A (o-p)) | 11.0 |
| Regenerative brake frequency (times/min) | Without option :No limit With option :No limit Option (External regenerative resistor) Part No. : DV0P4283 |
| About regenerative brake frequency | Please refer to the details of [Motor Specification Description] , Note: 1, and 2. |
| Rated rotational speed (r/min) | 3000 |
| Rated rotational Max. speed (r/min) | 5000 |
| Moment of inertia of rotor ( x10-4 kg ⋅ m²) | 0.67 |
| Recommended moment of inertia ratio of the load and the rotor | 30 times or less |
| About recommended moment of inertia ratio of the load and the rotor | Please refer to the details of [Motor Specification Description] ,Note: 3. |
| Rotary encoder: specifications | 20-bit Incremental system |
| Rotary encoder: Resolution | 1048576 |
Permissible load
| Item | Specifications |
|---|---|
| During assembly: Radial load P-direction (N) | 392 |
| During assembly: Thrust load A-direction (N) | 147 |
| During assembly: Thrust load B-direction (N) | 196 |
| During operation: Radial load P-direction (N) | 245 |
| During operation: Thrust load A, B-direction (N) | 98 |
| About permissible load | For details, refer to the [Motor Specification Description] "Permissible Load at Output Shaft". |
MHMJ042G1C
Specific References
- UPC
- MHMJ042G1C
- MPN
- MHMJ042G1C
