Panasonic MINAS A6 MQMF041L84N Servo Motor 100V 400W
$0.00
Tax included
Panasonic MINAS A6 MQMF041L84N Servo Motor 100V 400WExperience unparalleled precision and performance with the Panasonic MINAS A6 MQMF041L84N Servo Motor, a pinnacle of cutting-edge engineering in motion control technology.Key Features:High Precision Control: Engineered to deliver exceptional precision and accuracy in motion control applications, ensuring smooth and reliable operation.High Torque Output: With a power rating of 400W, this servo motor provides robust torque output for demanding industrial and automation tasks, ensuring optimal performance even in challenging conditions.Advanced Technology: Leveraging state-of-the-art technology, this servo motor offers exceptional responsiveness and dynamic control, making it ideal for applications requiring rapid and precise movement.Compac
Security policy
(edit with the Customer Reassurance module)
Delivery policy
(edit with the Customer Reassurance module)
Return policy
(edit with the Customer Reassurance module)
Panasonic MINAS A6 MQMF041L84N Servo Motor 100V 400W
Experience unparalleled precision and performance with the Panasonic MINAS A6 MQMF041L84N Servo Motor, a pinnacle of cutting-edge engineering in motion control technology.
Key Features:
High Precision Control: Engineered to deliver exceptional precision and accuracy in motion control applications, ensuring smooth and reliable operation.
High Torque Output: With a power rating of 400W, this servo motor provides robust torque output for demanding industrial and automation tasks, ensuring optimal performance even in challenging conditions.
Advanced Technology: Leveraging state-of-the-art technology, this servo motor offers exceptional responsiveness and dynamic control, making it ideal for applications requiring rapid and precise movement.
Compact Design: Designed with a compact footprint, this servo motor maximizes space efficiency while maintaining superior performance, perfect for installations where space is a premium.
Versatile Compatibility: Compatible with a range of systems and applications, ensuring seamless integration into your existing setup for enhanced operational efficiency.
Technical Specifications:
- Model: MINAS A6 MQMF041L84N
- Voltage: 100V
- Power: 400W
- Type: Servo Motor
- Precision: High precision control
- Torque: High torque output
- Compatibility: Versatile compatibility with various systems
- Compact Design: Space-efficient design
Applications:
- CNC machinery
- Robotics
- Industrial automation
- Packaging machinery
- Printing equipment
Why Choose Panasonic MINAS A6 MQMF041L84N Servo Motor?
- Unrivaled precision and performance
- Reliable and durable design
- Seamless integration into existing systems
- Superior technology for optimal control and responsiveness
- Trusted Panasonic quality and engineering excellence
Optimize your industrial processes with the Panasonic MINAS A6 MQMF041L84N Servo Motor, setting a new standard in precision and reliability.
For more information or to order, contact us today.
Spec Detail
| Item | Specifications |
|---|---|
| Part Number | MQMF041L84N |
| Details | Servo motor with Gear reducer, Middle inertia, Lead wire type, IP44 |
| Family Name | MINAS A6 |
| Series | MQMF Series |
| Type | Middle inertia |
| Enclosure | IP44 |
| About Enclosure | at gear reducer |
| Environmental Conditions | For more details, please refer to the instruction manual. |
| Motor lead-out configuration | Lead wire |
| Motor encoder connector | Lead wire |
| Power supply capacity (kVA) | 0.9 |
| Voltage specifications | 100 V |
| Rated output | 400 W |
| Rated current (A (rms)) | 4.1 |
| Holding brake | with |
| Mass (kg) | 5.9 |
| Gear reduction ratio | 1/25 |
| Gear type | For high precision |
| Shaft | Key-way, center tap |
| [About Characteristic of Gear Reducer] | The output, rated rotational speed, maximum rotational speed, rated torque, instantaneous maximum torque of the geared servomotor are values on the output shaft of the gear. |
| Output (W) | 327 |
| Rated torque (N ⋅ m) | 26.0 |
| Continuous stall torque (N ⋅ m) | 1.40 |
| Momentary Max. peak torque (N ⋅ m) | 96.9 |
| Max. current (A (o-p)) | 20.3 |
| Regenerative brake frequency (times/min) | Without option :No limit With option :No limit Option (External regenerative resistor) Part No. : DV0P4282 |
| Rated rotational speed (r/min) | 120 |
| Rated rotational Max. speed (r/min) | 260 |
| Moment of inertia of rotor ( x10-4 kg ⋅ m²) | 1.39 |
| Recommended moment of inertia ratio of the load and the rotor | 10 times or smaller |
| Rotary encoder: specifications | 23-bit Absolute/Incremental system |
| Notice | When using a rotary encoder as an incremental system (not using multi-turn data), do not connect a battery for absolute encoder. |
| Rotary encoder: Resolution | 8388608 |
Brake specifications
| Item | Specifications |
|---|---|
| Static friction torque (N ⋅ m) | 1.6 or more |
| Engaging time (ms) | 70 or less |
| Releasing time (ms) | 20 or less |
| Exciting current (DC) (A) | 0.36 |
| Releasing voltage (DC) (V) | 1 or more |
| Exciting voltage (DC) (V) | 24 ± 2.4 |
| About brake specifications | This brake will be released when it is energized. Do not use this for braking the motor in motion. Please refer to the details of [Motor Specification Description] , "Specifications of Built-in Holding Brake" and "Notes on [Motor specification] page, Note: 4. |
Permissible load
| Item | Specifications |
|---|---|
| Radial load (N) | 2060 |
| Thrust load (N) | 1030 |
MQMF041L84N
